Holset HX35 turbo - Original
This turbo fits on a motor that is from 2 - 7 liters. The turbocharger is with internal wastegate.
This turbocharger has a T3 flange on the supply side with split entry.
Holset HX 35 turbo info:
Compressor wheel 52 / 82mm.
Exhaust wheels 58 / 65mm.
Oil cooled / 360 ° bearing
Output is 5 bolted - But not one we have - But if you make a flange for it you can use this 5 bolted flange to bolt on top. Then you have the option of mounting this 3 "V band flange .
You can use this kit for return turbochargers .
Output for turbo pressure is with V-band flange that can be used a 2½ ". However, the flange included must be turned slightly to be able to tighten properly. On the link above you can find V band flanges.
A 4 "air filter must be used for the suction .
Possibly. for diesel tuning up to 325 hp.
"Super tractor turbo"
