PDM12 Motorsport Button Panel & Relay Module is a modern and user-friendly solution for anyone who wants to replace traditional fuses, relays, buttons, and switches with a more compact and professional electrical system. The kit combines a digital power distribution unit with a weather-protected CAN keypad, giving you full control over the vehicle’s electrical functions in one complete solution.
PDM12 and KEY12 are suitable for many different applications and can be used in everything from motorsport cars and road cars to boats, machinery, ATVs, snowmobiles, jet skis, and motorhomes. The system makes it possible to control a wide range of functions such as fuel pump, starter motor, cooling fan, cabin fan, ECU, lighting, windscreen wipers, water pump, boost control, NOS, and much more. This provides a cleaner electrical setup and a far more modern solution than a traditional fuse and relay box.
PDM12 is a compact and programmable relay and fuse box with 12 outputs that can be set individually as needed. Each output can be programmed for functions such as on/off, momentary, pulse, strobe, or indicators / hazard lights. The built-in circuit alarm with indicator on each output provides extra safety and makes it easier to monitor the system.
KEY12 is a waterproof and programmable CAN keypad that works together with PDM12 and replaces traditional buttons and switches. With interchangeable buttons and multiple colour options, the keypad can be adapted precisely to your project. This makes the system ideal for both motorsport and custom-built vehicles where a clean, simple, and professional installation is required.
PDM12 + KEY12 is a strong combination of price, function, ease of use, and durability. Installation is simple, and the system is designed to handle demanding environments where vibrations, moisture, and dust place high demands on the components.
Specifications
Number of outputs: 12 programmable outputs
Output configuration: 4x5A, 4x10A, 4x20A, 4x30A
Button colours: Red, purple, blue, white, green, orange, yellow
Communication: CAN between PDM12 and KEY12
Safety: Circuit alarm with indicator on each output
Voltage: 12/24 Volt (8-32V)
Max. current: 100A
Shock resistant: Yes
Operating temperature: -40 to +90 degrees
Classification: IP68
Protection: Dustproof and waterproof
Included
1x Digital fuse box PDM12
1x Keypad KEY12
1x Mounting bracket
1x 2 metre cable for KEY12
1x Red power cable for PDM12 approx. 63 cm
1x Red power cable for PDM12 approx. 28 cm
1x Black power cable for PDM12 approx. 63 cm
1x Circuit breaker
1x Set with approx. 50 icons for KEY12
1x Set of screws, nuts, and fuses
Clear installation guide
